Overview
Mimaki TS300P wide format dye sublimation inkjet printer
The 77-inch wide, roll-to-roll TS300P-1800 printer is a dedicated transfer paper model, offering new levels of quality and productivity for digital textile printing or applications requiring transfer to hard surfaces. This printer was specifically engineered for the dye sublimation industry. Designed to print onto the thinnest of transfer paper, it includes a high gap printhead that is unaffected by cockling that is a common occurrence when using thin media, while maintaining extremely high quality output. High print speeds of up to 1238 SqFt/Hr can be achieved in four-color mode. New Sb410 inks with enhanced resolvability improve print production yields.
Mimaki TS300P-1800 Series GO BEYOND Conventional
- Dedicated transfer paper printer
- Includes technologies for printing onto thin transfer media without cockling interference
- 77-inch (1950 mm) width
- Productivity of up to 1238 SqFt/hr (115 SqM/hr)
- New Sb410 dye sublimation inks with improved stability
- Two liter link bottles for all colors
- Variable dot printing for exceptional image quality
- MAPS4 for smooth images
- Nozzle Check Unit and Nozzle Recovery System
- Ethernet and email notification
Features
Highlights of the Mimaki TS300P-1800 Printer
Dedicated transfer paper printer
The TS300P was specifically engineered for the dye sublimation industry. Designed to print onto the thinnest of transfer paper, it includes a number of technologies that enable printing on thin transfer media, while maintaining extremely high quality output.
High gap printhead
Thin transfer papers – desirable because of more square footage per roll – are susceptible to cockling, creating media transport problems and potential head strikes. The TS300P printer employs a new printhead that ensures accurate ink droplet placement with a high head gap, enabling high quality printing on thin transfer paper.
Media handling system
A powerful vacuum feed platen holds media taut, while larger media press plates minimize cockling by reducing media uplift immediately after printing. The Auto Media Feeder applies calibrated tension to the media, maintaining stable and precise media feed and take-up.
Production print speeds
The TS300P printer delivers high productivity with print speeds of up to 1238 square feet (115 square meters) per hour in four-color mode. Print speeds of up to 700 square feet (65 square meters) per hour can be achieved in six-color mode.
New Sb410 inks
Mimaki-developed and manufactured Sb410 sublimation inks offer enhanced resolvability, which improves the print production yield by ensuring more stable ink jetting. Moreover, because the ink stability is improved, daily cleaning is easier and fewer regular cleanings are required, further contributing to cost reduction and higher throughput. A two-liter bulk ink system is standard.
Workflow enhancements
The TS300P printer can be connected to a network via Ethernet (or USB 2.0) connection, for flexibility in setting up the workflow. Via the Remote Event Notification feature, it can relay status information such as start, finish or error messages to a mobile phone or computer.
Applications
What you can do with the Mimaki TS300P-1800 Printer
With eco solvent inks:
- Performance apparel
- Fashion textiles
- Soft Signage
- Backlit fabric signage
- Exhibit graphics
- Banner
- Flags
- Interior Décor
- and more…
Specifications
Technical overview of the Mimaki TS300P-1800 Printer
| Print system | On-demand piezo, four print heads in an in-line configuration |
| Max print width | 76.4 inches (1940 mm) |
| Print resolutions | 60, 540, 720, 1080, 1440 dpi |
| Max print speed |
1238 SqFt/Hr (115 SqM/Hr) in four-color mode 700 SqFt/Hr (65 SqM/Hr) in six-color mode |
| Ink type | Mimaki Sb410 dye sublimation ink: Bl, M, Y, K, Lbl, Lm |
| Ink capacity | 2 liter bottle |
| Max roll weight | 88 lbs. (40 kg) |
| Operational environment |
Temp: 68? – 86? F (20? – 30? C) 35-65% RH (non-condensing) |
| Connectivity | USB 2.0, Ethernet 1000Base-T |
| Power supply | Single-phase AC 100-120V (AC 220-240V), printer only |
| Dimensions (W x D x H) | 126 x 33.5 x 73.1 inches (320 x 85 x 186 cm), printer only |
| Weight | 470 lbs. (213 kg) |
Gallery
Gallery
Brochure
JV300 Series
Technical
Ink for the Mimaki TS300P-1800 Printer
Sb300 Dye Sublimation Ink
- Blue: 2 liter ink pouch, Sb410-BLT-2L
- Magenta: 2 liter ink pouch, Sb410-MT-2L
- Yellow: 2 liter ink pouch, Sb410-YT-2L
- Black: 2 liter ink pouch, Sb410-KT-2L
- Light Blue: 2 liter ink pouch, Sb410-LBT-2L
- Light Magenta: 2 liter ink pouch, Sb410-LMT-2L
Software Mimaki TS300P-1800 Series
RasterLink6 software is included.
Choose TxLink3 software, designed for textile printing.
Use the below link for more information on Supplies available for the TS300P-1800 Series. (Note that not all Supplies configurations are available in all geographies – check with your Mimaki customer service representative or Mimaki authorized dealer for available stock.)
TS300P-1800 Series Supplies
You may also be interested in:
SMART Program
The School of Mimaki Application and Resource Training (SMART) Program includes comprehensive training for end-users and dealers. Classes include Vinyl Wraps for Beginners and Optimizing Output using RasterLink6 Software and more. Advanced technical support programs for authorized dealers are also offered.
Please click here for frequently asked questions of TS300P-1800 Printer
