Overview
Mimaki TS34-1800A wide format dye sublimation inkjet printer
The TS34-1800A printer can print onto transfer media up to 74.8 inches wide. In four-color mode, it can print at speeds of up to 344 SqFt/Hr. The standard Uninterrupted Ink Supply System ensures continued printing by switching automatically to a second cartridge when the first one is out of ink. Or select the optional bulk ink system that uses 2-liter ink packs. It ideal for the soft signage market for producing retail banners and flags. It is also well-suited for sportswear applications due to the durability and quick drying capability of polyester material.
TS34-1800A Go Beyond
- Print on transfer media up to 74.8 inches (1900 mm) wide
- High resolution printing of up to 1440 dpi
- Print speeds of up to 344 SqFt/Hr (32 SqM/Hr)
- Dye sublimation inks transfer to a variety of polyester fabrics
- Variable dot printing for exceptional image quality
- Uninterrupted ink supply system
- Optional Mimaki Bulk Ink System (MBIS) available
- Equipped with roll take-up device, inside / outside selectable
- 74.8-inch (1900 mm) width
Features
Highlights of the Mimaki TS34-1800A Printer
Print on Economical Transfer Media
With the TS34-1800A printer, you can print directly to economical transfer media, for post-processing to polyester or coated media. Produce flags, banners, sports apparel or any number of soft signage applications.
Variable Drop Printing Produces Smooth Images
The advantage of variable drop printing is most apparent when printing color gradations in light or pastel colors. In addition, variable drop printing delivers fine, high resolution prints that are less granular by jetting two different ink drop sizes at a time.
Fast print speeds
The TS34-1800A dye sublimation inkjet printer can print at high speeds up to 344 SqFt/Hr (34 SqM/h).
Uninterrupted Ink Supply System
Utilizing the UISS (Uninterrupted Ink Supply System) in 2X-CMYK mode, when one cartridge is emptied, the printer automatically switches to the full cartridge of the same color to deliver continuous imaging.
Mimaki Bulk Ink System (optional)
The optional MBIS features economical, high-capacity 2 liter ink packs, and is a great solution for long running jobs.
Applications
What you can do with the Mimaki TS34-1800A Printer
- Performance apparel
- Fashion textiles
- Soft signage
- Backlit fabric signage
- Exhibit graphics
- Banners
- Flags
- and more…
Specifications
Technical overview of the Mimaki TS34-1800A Printer
| Print system | On-demand piezo, two staggered print heads |
| Max print width | 74.8 inches (1900 mm) |
| Print resolution | 300, 540, 720, 1440 dpi |
| Max print speed | 344 SqFt/Hr (32 SqM/Hr) |
| Ink type | Mimaki Sb53 dye sublimation ink: Bl, M, Y, K, Lbl, Lm |
| Ink capacity |
Standard / UISS: 440 ml cartridges Optional / MBIS: 2 liter ink packs |
| Max media width | 75.2 inches (1910 mm) |
| Max roll weight | 55 lbs. (25 kg) |
| Operational environment |
Temp: 68? – 86? F (20? – 30? C) 35-65% RH (non-condensing) |
| Connectivity | USB 2.0 |
| Power supply | Single-phase AC 100-120V (AC 220-240V) |
| Dimensions (W x D x H) | 112 x 30 x 56 inches (284 x 75 x 143 cm) |
| Weight | 463 lbs. (210 kg) |
Gallery
Gallery
Brochure
JV300 Series
Technical
Ink for the Mimaki TS34-1800A Printer
Dye Sublimation ink (Sb54)
- Blue: 440ml cartridge, SB54-BL-44
- Magenta: 440ml cartridge, SB54-M-44
- Yellow: 440ml cartridge, SB54-Y-44
- Black: 440ml cartridge, SB54-K-44
- Light Blue: 440ml cartridge, SB54-LBL-44
- Light Magenta: 440ml cartridge, SB54-LM-44
Use the below link for more information on Supplies available for the TS34-1800A Series. (Note that not all Supplies configurations are available in all geographies – check with your Mimaki customer service representative or Mimaki authorized dealer for available stock.)
Supplies available for the TS34-1800A Series
