Overview
Mimaki CG-SRIII Series cutting plotters
The Mimaki CG-SRIII Series of roll-based cutters are available in three widths. These models feature continuous crop mark detection for precise contour cutting. A proprietary half cut function leaves a small bit of backing sheet at connecting points for easier handling. Accurate long-length cutting is enabled through segment compensation. These cutting plotters are ideal for producing decals, stickers, cut-vinyl signs and more.
CG-SR III Series Go Beyond
-
Three sizes available:
- CG-60SRIII: 29.1 inches (74 cm)
- CG-100FXIII: 49.2 inches (125 cm)
- CG-130FXIII: 61 inches (155 cm)
- Continuous crop mark detection
- Half cut function
- Segment compensation
- Over cut function
- Three selectable job speeds
- Media load from front or back
- Remote event notification function
- FineCut8 and SimpleCut software included
Features
Highlights of the Mimaki CG-SRIII Series
The Mimaki CG-SRIII Series roll-based cutting plotters include a number of features for producing a wide range of contour-cut pieces.
More application possibilities
A higher cutting pressure of 500g widens the range of materials for various applications. The clamp pressure can be adjusted to cover a wide range of sheets including thick materials. An optional sheet basket enables stable long-length cutting.
Continuous crop mark detection
A higher cutting pressure of 500g widens the range of materials for various applications. The clamp pressure can be adjusted to cover a wide range of sheets including thick materials. An optional sheet basket enables stable long-length cutting.
Segment compensation
Intermediate crop marks in the feed direction enable four-point corrections for each segment. This leads to accurate, long-length cutting, even if the image is distorted.
Intermediate crop marks can be made by Finecut
Half cut mechanism
A = Die cut
(through cut)
B = Half cut
(cut through half the media)
With the proprietary half cut function, the backing sheet can be cut leaving behind a small connecting point that can be easily detached when necessary. This enables easier handling when removing the contour cut piece from the sheet.
Event Notification function
Receive status messages through the email notification system for unattended operation.
Applications
What you can do with the Mimaki CG-SRIII Series
- Stickers
- Labels
- Decals
- Cut-vinyl signage
- and more…
Suitable Cutting Materials
(Colored) Vinyl, transparent PET, (transfer) paper, flock, rubber.
Specifications
Technical overview of the Mimaki CG-SRIII Series
| Type | Roll-based cutting plotter |
| Max media width |
CG-60SRIII: 29.1 inches (74 cm) CG-100SRIII: 49.2 inches (125 cm) CG-130SRIII: 61 inches (155 cm) |
| Effective cutting width |
CG-60SRIII: 23.8 inches (60 cm) CG-100SRIII: 42.1 inches (107 cm) CG-130SRIII: 53.9 inches (137 cm) |
| Max cutting speed | 27.5” (70 cm) per second |
| Max moving speed | 39.3” (100 cm) per second |
| Max downforce pressure |
Cutter: 10-20g (2g step), 20-100g (5g step), 100-500g (10g step) Pen: 10-20g (2g step), 20-100g (5g step), 100-150g (10g step) |
| Operational environment |
Temp: 41? – 95? F (5? – 35? C) 35-75% RH (non-condensing) |
| Connectivity | RS-232, USB, Ethernet |
| Power supply | AC100V-240V, 50/60 Hz |
| Dimensions (W x D x H) |
CG-60SRIII: 40.6 x16.9 x 46.6” (103 x 43 x 33 cm)* CG-100SRIII: 60.2 x 22.8 x 45.3” (153 x 58 x 115 cm) CG-130SRIII: 72 x 22.8 x 45.3” (183 x 58 x 115 cm) *height does not include optional stand |
| Weight |
CG-60SRIII: 60 lbs. (24 kg) CG-100SRIII: 90 lbs. (41 kg) CG-130SRIII: 101 lbs. (46 kg) |
Gallery
Gallery
Brochure
JV300 Series
Technical
Supplies for the Mimaki CG-SRIII Series
Popular tools:
-
- Swivel blade for PVC sheet, SPB-0001
- Swivel blade for small letters, SPB-0003
- Swivel blade for rubber sheet, SPB-0005
- Swivel blade for reflective sheet, SPB-0006
- Swivel blade for fluorescent sheet, SPB-0007
- Swivel blade for PVC (low pressure), SPB-0030
Use the below link for a complete list of Supplies available for the CG-SRIII Series. (Note that not all Supplies configurations are available in all geographies – check with your Mimaki customer service representative or Mimaki authorized dealer for available stock.)
