Overview
JV34-260 High productivity Mimaki JV34-260 super wide format inkjet printer
The JV34-260 super wide format printer offers productivity and functionality for a wide variety of applications. It can accommodate roll media up to 104-inches (263 cm) wide and print at speeds of up to 322 square feet (29.9 SqM) per hour. High quality output is achieved through variable dot printing and resolutions up to 1440 dpi. Available inks include eco-solvent for indoor/outdoor sign and graphics applications; or dye-sublimation inks for soft signage, textile and apparel applications. Two-liter bulk ink system available as an option.
JV34-260 Go Beyond
- Super wide format accommodates media up to 104 inches (263 cm)
- Print speeds up to 322 SqFt (29.9 SqM) per hour
- High quality print resolution of up to 1,440 dpi
- Variable dot printing for smooth images
- Choice of eco solvent or dye sublimation ink sets
- 3-stage intelligent heater
-
Uninterrupted Ink Supply System
- Bulk Ink System available as an option
- Media Feed System
Features
Highlights of the Mimaki JV34-260
Super wide production
The JV34-260 lets you go big with the ability to print to media up to 104 inches (2642 mm) wide. Produce banners, oversized signage, transit advertising and more.
Two inksets available
Select Mimaki SS21 eco solvent inks for outdoor durable applications that can also be used indoors due to low VOCs. Or choose the dye sublimation inkset that can print to low-cost paper transfer media for digital textile, soft signage, apparel and interior décor applications.
Uniform media drying
A three-way intelligent heating system results in uniform ink drying across the width of the printer, assuring even image quality. Additionally, a drying fan supplements the heaters so finished prints can be handled immediately.
Uninterrupted Ink Supply System
When printing in CMYK, the JV34-260 printer can be configured with two ink cartridges per color. Utilizing the UISS (Uninterrupted Ink Supply System) when one cartridge is emptied, the printer automatically switches to the full cartridge to deliver continuous imaging. A bulk ink system featuring 2-liter ink bags is available as an option.
Media Feed System
Media up to 220 lbs. (100 kg) is transported evenly without being affected by the varying weight of the roll, eliminating banding caused by irregular feeding. The JV34-260 model is equipped with both a heavy-duty media feeding system and a convenient small take-up device.
Available in solvent and dye sublimation model
Water-based sublimation ink and solvent ink can be used in JV34-260, enabling a wide variation of applications, including signs, flags, banners, sublimation printing for polyester, etc.
Please note that ink type must be chosen at time of installation. Sublimation printing corresponds to printing on transfer paper.
Applications
What you can do with the Mimaki JV34-260
With solvent inks (application-dependent):
- Banners
- Backlit signs
- Pop displays
- Floor graphics
- Labels
- Posters
- High quality stickers
- Vehicle wrap
- Window signage
- and more…
With dye sublimation inks:
- Flags
- Fashion & sportswear
- Promotional
- Exhibition soft signage
- T-shirt transfers
- Interior design and furnishing
- and more…
Specifications
Technical overview of the Mimaki JV34-260
| Print system | On-demand piezo, two staggered print heads per color |
| Max print width | 103.6” (2632 mm) |
| Print resolutions | 540, 720, 1080 and 1440 dpi |
| Max print speed* |
322 SqFt (29.9 SqM) per hour *print speeds calculated using solvent inks |
| Ink type |
Mimaki SS21 eco solvent ink: C, M, Y, K, Lc, Lm Mimaki Sb54 dye sublimation ink: BL, M, Y, K, Lbl, Lm |
| Ink capacity |
440ml ink cartridge 2 liter bulk Ink system available as an option |
| Max media width | 104” (2642 mm) |
| Max roll weight | 220 lbs. (100 kg) |
| Operational environment |
Temp: 68? – 95? F (20? – 35? C) 35-65% RH (non-condensing) |
| Connectivity | USB 2.0 |
| Power supply | AC 100-120, AC220-240, 50/60Hz |
| Dimensions (W x D x H) | 144 x 51 x 56 (265 x 130 x 142 cm) |
| Weight | 1025 lbs. (465 kg) |
Gallery
Gallery
Brochure
JV300 Series
Technical
Ink for the Mimaki JV34-260
Note: not all ink configurations are available for all models. Check with your representative before ordering.
Eco Solvent ink (SS21)
- Cyan: 440ml cartridge, SPC-0501C
- Magenta: 440ml cartridge, SPC-0501M
- Yellow: 440ml cartridge, SPC-0501Y
- Black: 440ml cartridge, SPC-0501K
- Light Cyan: 440ml cartridge, SPC-0501LC
- Light Magenta: 440ml cartridge, SPC-0501LM
Dye Sublimation ink (Sb54)
- Blue: 440ml cartridge, SB54-BL-44
- Magenta: 440ml cartridge, SB54-M-44
- Yellow: 440ml cartridge, SB54-Y-44
- Black: 440ml cartridge, SB54-K-44
- Light Blue: 440ml cartridge, SB54-LBL-44
- Light Magenta: 440ml cartridge, SB54-LM-44
Use the below link for more information on Supplies available for the JV34-260. (Note that not all Supplies configurations are available in all geographies ? check with your Mimaki customer service representative or Mimaki authorized dealer for available stock.)
JV34-260 Printer Supplies
You may also be interested in:
RasterLink6 software
Sophisticated RIP software maximizes performance. Includes intuitive icons that make option selections easy-to-use with a single-window interface.
SMART Program
The School of Mimaki Application and Resource Training (SMART) Program includes comprehensive training for end-users and dealers. Classes include Vinyl Wraps for Beginners and Optimizing Output using RasterLink6 Software and more. Advanced technical support programs for authorized dealers are also offered.
Please click here for FAQ of JV34-260 Series
