Overview
Kebab option: 360-degree direct printing on cylindrical products
The Kebab option enables printing directly onto cylindrical objects such as bottles and candle holders. It is available for use on the UJF-3042HG or UJF-6042 printers.
The Kebab option
- 360-degree direct printing on cylindrical objects
- Print on bottles, candles, cans, etc.
- Easy mounting on the UJF-3042HG and UJF-6042
- User-friendly print settings and functions via RasterLink6 software
- Intuitive operation
Features
Highlights of the Mimaki Kebab
Printing 360 degree on the surface of a cylindrical object
The Kebab option enables printing on cylindrical objects ranging from about one to 13 inches in length, with a diameter from 0.4 to 4.33 inches. Add this option to a UJF-3042HG or UJF-6042 model produce custom products such as personalized beverage bottles, candles, vases, cans, etc.
Applications
What you can do with the Mimaki Kebab
- Glass bottles
- Aluminum containers
- Plastic novelties
- Candle holders
- and more…
Specifications
Technical overview of the Mimaki Kebab option
| Printer compatibilityl |
UJF-3042HG UJF-6042 |
| Rotary degree of print material | + / – 360 degrees (no limitation)/td> |
| Rotation system | Cylindrical rollers |
| Printable area |
Diameter: 0.39 to 4.33 inches (10 to 110mm) Length: 1.18 to 12.99 inches (30mm to 330mm) |
| Printable size |
Feeding direction (X): entire surface of material Print head movement direction (Y): 11.81” (300mm) or less |
| Max. weight of printed material | 6.61 lbs. (3 kg) |
| Operational environment | Same as UJF printer |
| Unit dimensions (W x D x H) |
15.7 x 13 x 2 inches (400 x 330 x 51 mm) |
| Unit weight | 4.4 lbs. (2 kg) |
